Includes full KAT WOB Candy Keycap Base and Accents worth $185.

Introducing the Zoom75 HE Pre-Built Keyboard, a magnetic switch version of Meletrix's popular Zoom75. Meletrix's HE module and magnetic switches for lightning fast responses for gamers - especially FPS enthusiasts. Current Zoom75 users can also upgrade their board by purchasing an independent HE module. Enhance your gaming experience with the Zoom75 HE Pre-built - where customization meets performance.

Zoom75 HE at a Glance:

Magnetic Switch

Traditional mechanical keyboards require pressing the switch and reaching the actuation point to activate a key. In contrast, magnetic switches operate differently. They comprise a bottom Hall sensor and an upper magnet. When a key is pressed, changes in the distance within the sensing magnetic field lead to a fluctuation in current. Activation is determined by evaluating the strength of the induced current.
Additionally, automatic calibration via the Baseline Calibration algorithm ensures no abnormal functions due to temperature, humidity, magnetic differences, etc.

Adjustable Activation Point

Zoom75 HE magnetic enables you to gain the upper hand in game. Our Zoom75 HE enables key activation at distances as short as 0.1mm. You can customize the activation point for each key, ranging from 0.1mm to 4.0mm. Find the ideal key travel distance that suits you best.

Rapid Trigger:

Utilizing the unique traits of magnetic switches, key activation and reset are determined by the distance traveled rather than fixed points. This precision enables keys to activate upon pressing and reset upon release, facilitating seamless consecutive key presses. This capability empowers you to swiftly execute a series of actions during gaming.

Switch Specifications:

Product Name: GATERON KS-37B Magnetic Hall Sensor Keyboard Switch
Initial Force:30±10gf.
Total travel:4.0±0.2mm.
Operation Lifetime:150,000,000 Cycles.
Bottom Force: 50±10gf.
Top Housing Material: Thermoplastic, Transparent
Bottom Housing Material: Thermoplastic, Red
Stem Material: Thermoplastic, Red
Spring Material: Stainless steel

Keyboard Specifications:

Mount Style: Gasket
Layout: 75%
PCB: 1.6mm thickness, with Ai03 DB
Typing Angle: 5°
Front Height: 22.14mm
Dimension: 323.6 x 145.78 x 34.73 (mm)
Default plate: Aluminum
Case Material: 6063 Aluminum
Case Finish: Electrostatic glitter white top and bottom case
Backplate: White: PVD silver back plate Black: PVD black back plate
External Weight: White: Anodized gold weight Black: Anodized gold weight
Keycaps:

ZOOM75 HE Black Prebuilt: WOB Keycaps
ZOOM75 HE White Prebuilt: BOW Keycaps

Switches: Gateron KS37B, c ompatible with KS37
Switch Orientation: North Facing
Boog75 Wired Polling Rate: 1000hz
QMK or VIA Support: No, customization requires use of an independent driver
Total Weight: 3kg

Keycap Specifications:

Manufacturer: Keyreative
Keycap Material: Double-shot PBT
Keycap Thickness: 1.6mm
Keycap Profile: KAT
Keys QTY: 81 keys

What's in the box?

Fully Assembled Keyboard, including:

Top and bottom cases
HE Module (Magnetic Switch, Plate, Gasket, Sound absorbing foam, and PCB)
Case foam
BOW/WOB keycaps (matching case color)
Tools
Accessories

FAQs:

Is the PCB only compatible with the Zoom 75?
Yes!
Will it support LCD Module or Knob Module?
Only the 2-Keys module is supported.
Can I only buy the case of the Boog75?
Unfortunately, no.
